1.Adopt spur gear transmission,after carburizing and quenching treatment,tooth to tooth wide practice treatment,surface sandblasting and nickel plating,stable operation of equipment,low noise.

2.Simple structure,fast delivery time,mass production.

3.There are a variety of reducer,which can meet most of the working conditions in the market.

TVFR系列性能參數表 / TVFR Series Performance Table
規格 Specification	單位 Unit	節數Stage	減速比Ratio	TVFR60	TVFR80	TVFR90	TVFR120	TVFR160
額定輸出力矩Rated output torqueT_2N	Nm	1	3	18	40	50	125	290
			4	36	90	110	230	460
			5	40	110	125	260	550
			6	20	40	50	90	340
			7	20	40	50	90	340
			8	12	22	32	70	210
			10	12	22	32	70	210
		2	15	40	110	125	260	550
			20	40	110	125	260	550
			25	40	110	125	260	550
			30	18	40	50	125	290
			35	40	110	125	260	550
			40	36	90	110	230	460
			50	40	110	125	260	550
			60	20	40	50	90	340
			70	20	40	50	90	340
			80	12	22	32	70	210
			100	12	22	32	70	210
		3	64	40	110	125	260	550
			80	40	110	125	260	550
			100	40	110	125	260	550
			150	40	110	125	260	550
			200	40	110	125	260	550
			250	40	110	125	260	550
			350	40	110	125	260	550
			400	40	110	125	260	550
			500	40	110	125	260	550
			700	20	40	50	90	340
			1000	12	22	32	70	210
急停扭矩 / Emergency stop torqueT_2NOT	Nm	1,2,3	3 ?1000	二倍額定輸出力矩 / Triple rated output torque
額定輸入轉速 / Rated input speed η_1N	rpm	1,2,3	3-1000	5000	4000	4000	3000	3000
******輸入轉速 / Maximum input speed η_1B	rpm	1,2,3	3-1000	10000	8000	8000	6000	6000
扭轉剛性 / Torsional rigidity	Nm/arcmin	1,2,3	3-100	7	14	25	50	145
容許徑向力 / Allowable radial force F_2aB	N	1,2,3	3-1000	1530	3250	6700	9400	14500
容許軸向力 / Allowable axial force F_2aB	N	1,2,3	3-1000	765	1625	3350	4700	7250
使用壽命 / Lifespan	hr	1,2,3	3-1000	20000
效率 / Efficiency	%	1	3?100	≥97%
	%	2,3	15 ~ 1000	≥94%
重量 / Weight	kg	1	3~10	2.1	5	5	8.8	30
		2	15 ?100	2.7	6	6	10.8	34
		3	64-1000	3.3	7	7	12.8	37
使用溫度 / Working temperature	°C	1,2,3	3-1000	-10°C~90°C
潤滑 / Lubricating		1,2,3	合成潤滑油脂 / Synthetic lubricating grease
防護等級 / IP Grade		1,2,3	3-1000	IP65
安裝方向 / Installation direction		1,2,3	3-1000	任意方向 / In any direction
噪音值(n1=3000rpm,無負載) Noise level (η1=3000rpm,off load)	dB(A)	1,2,3	3 ?100	≤58	≤60	≤63	≤65	≤65
